Armoloq TPA-AT578
*Base Package includes the TPA protective mounting platform only. All additional accessories, components and RF packages are sold as an optional add on or can be purchased separately under the Optional Packages and Components page.
Base package includes the following-
TPA-AT578, protective mounting platform
M4-0.7 x 10mm- 4, these mounting screws are the proper length for attaching the TPA to the radio. Not to be used without the TPA pack frame.
Optional Packages-
RF PnP Package, PL-TNC/STRT3
This package includes the following components-
PL-259 straight to TNC male, terminated to RG58C/U- 1ft
TNC bulkhead, female- 1
TNC male to BNC female adapter- 1
Relocation mount with hardware- 1
Armoloq DDM-BT01
Anytone BT-01 is not included. This product is designed to function with the Bluetooth connection option of the BT-01, meaning there is no accommodation for hardwiring via an RJ45.
The Armoloq DDM-BT01 is a folding style Kydex holster for the Anytone BT-01. The BT-01 can be secured to the holster via the provided hardware or with only the shock cord for easier removal, depending on the operating scenario.
Product Description-
Fits the following radios- Anytone AT-D578, all flavors
Special Notes:
The TPA is a two piece protective mounting platform that is secured to the radio's 4 side mounting holes. The TPA provides protection to the radio body and control head with a wrap around design while allowing access to all controls.
Material- 5052 aluminum, 1/8"
Finish- powder coat, matte black
Dimensions
Length- 9.375 in
Length with MBS-1280- 14.500 in
Depth - 2.250 in
OAW-
Weight
TPA only- .750 lbs
TPA + radio-
TPA + radio + MBS-1280 + LiFePo4 10AH battery- 6.750 lbs
